Brinell Hardness Testing Machine

Brinell Hardness Testing Machine

5000-200000 INR/Set

Product Details:

X

Price And Quantity

  • 5000-200000 INR/Set
  • 1 Set

Trade Information

  • 1 Set Per Month
  • 2-3 Days

Product Description

We are able to gain huge popularity in the industry, by manufacturing and supplying an excellent range of Brinell Hardness Testing Machine. Manufactured using top grade materials and latest technology, these machines are ideal for rockwell as well brinell tests. Easy to install and maintain, Brinell Hardness Testing Machine is recognized over the global platform for their strong construction, accurate measurement and longer service life. In addition, we provide this machines in the qualitative packaging to avoid damage during transportation.

Technical Specifications :

Model

B-3000 (H)

B-3000 (O)

Loads kgf

250 to 3000 in stages of 250

250 to 3000 in stages of 250

Initial Load kgf

250

NIL

Max. test height mm

410

380

Depth of throat mm

200

200

Max. depth of elevating screw below base (approx.) mm

180

180

Machine height (approx.) mm

1127

1185

Net weight (approx.) kg

450

500

Driver motor HP

0.3

0.33

Mains supply V / cy / ph

415 / 50 / 3

415 / 50 / 3

Optical Device

NIL

Direct reading optical device with 10 x magnification

Standard Accessories:

Model

B-3000 (H)

Testing Table 200 mm dia

1 pc.

Testing table 70 mm dia with 'V' groove for round jobs - 10 to 80 mm dia

1 pc.

Ball holder 5 mm

1 pc.

Ball holder 10 mm

1 pc.

Test Block HB-5 / 750

1 pc.

Test Block HB-10 / 3000

1 pc.

Brinell Microscope

1 pc.

Allen Spanner

7 pcs.

Telescopic Cover for elevating screw protection

1 set

Instruction Manual

1 Book


HEAT TREATMENT SALES & SERVICES

* Tips on getting accurate quotes. Please include product name, order quantity, usage, special requests if any in your inquiry.

Other Products in 'Rockwell Hardness Tester' category
