Digital Rockwell Hardness Tester

Name: Digital Rockwell Hardness Tester
Brand: HEAT TREATMENT SALES & SERVICES
Price: 31500 INR
Availability: InStock

31500 INR/Set

Get a Price/Quote

Product Details:

Power Supply Electric
Operate Method Automatic
Color White
Usage Industrial
Product Type Digital Rockwell Hardness Tester
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Digital Rockwell Hardness Tester Price And Quantity

Minimum Order Quantity 1 Set
Price 31500 INR/Set

Digital Rockwell Hardness Tester Product Specifications

Product Type Digital Rockwell Hardness Tester
Usage Industrial
Color White
Power Supply Electric
Operate Method Automatic

Digital Rockwell Hardness Tester Trade Information

Supply Ability 1 Set Per Month
Delivery Time 2-3 Days

Product Description

We are well known in the market for Manufacturing and supplying Rockwell cum Rockwell Superficial Hardness Tester ( TWIN ). This Rockwell cum Rockwell Superficial Hardness Tester ( TWIN ) is manufactured with latest technology. They offer the facility of Automatic load selection with automatic zero setting dial gauges. They are operated manually. They are guided with a Diamond holder is in a ball cage, which enables testing of small pins having diameter Less than 6 mm (up to 3mm diameter).

Technical Specifications:

Model	Unit	TWIN
Loads	kgf	15, 30, 45 (Superficial) 60, 100, 150 (Rockwell)
Initial Load	kgf	3 (Superficial) 10 (Rockwell)
Max. Test Height	mm	330
Depth of Throat	mm	150
Max. depth of elevating screw below base	mm	355
Size of base	mm	210x474
Machine Height	mm	850
Net Weight	kg	100

Standard Accessories:

Model	TWIN
Testing table 50mm dia	1 pc.
Testing Table 38mm dia with V groove for round jobs 6 to 45mm dia.	1 pc.
Diamond Indenter 120o	1 pc.
Steel ball indenter 1/16	1 pc.
Test Block Rockwell C	1 pc.
Test Block Rockwell B	1 pc.
Test Block Rockwell Superficial N	1 pc.
Allen Spanners	5 pcs
Clamping Device	1 pc.
Dash Pot Oil	1 Book
Rubber bellow for elevating screw protection	1 pc.
Instruction Manual	1 Book
Brinell Microscope	NIL
Steel Ball Indenter 2.5mm	NIL
Test Block HB 2.5/187.5	NIL
Steel Ball Indenter 5mm	NIL

udicial mix of men and machinery has enabled us in meeting the requirements of our clients by offering a large range of Digital Rockwell Hardness Tester. We are manufacturing our testing equipments from top quality of raw materials and upgraded technologies with the support of our highly qualified technicians. Digital Rockwell Hardness Tester is used for permeability tests of specimen having wide range of diameters with half of its diameter. Our offered tester is available to clients at cost effective prices.

Technical Specifications :

Model	Unit	RASN (ET)
Major Load	N (kgf)	147.1, 294.2, 441.3, 588.4, 980.7, 1471 (15, 30, 45, 60, 100, 150)
Minor Load	N (kgf)	29, 42, 98.07
(3, 10)
Max Test Height	mm	230
Depth of Throat	mm	133
Net Wt. Approx	kg.	73
M/c Dimensions	mm	L-450, W-175, H-6

Specifications :

Model	RASNET-1
Type	Digital Rockwell Superficial
Operation Cycle	Automatic Load/Dwell/Unload
Preliminary Test Force	28.42 N (3 kgf) and 98.07 N (10 kgf)
Additional Test Force	177.7, 264.8, 411.9, 490.3, 882.6, 1373 N (12, 27, 42, 50, 90, 140 kgf)
Total Test Force	147.1, 294.2, 441.3, 588.4, 980.7, 1471 N (15, 30, 45, 60, 100, 150 kgf)
Test Force Selection	By external dialing
Set Position	With LCD bar indicator
Key board entry	Through membrane switch for Scale, GO-NO GO & dwell time section
Resolution	0.1 Rockwell or 0.1 Rockwell Superficial
Output	Parallel output for connecting dot matrix Printer to get results indicating serial no. of tests, hardness scale, hardness value & high/good/low indication.
Optional	Serial PC interface & windows Software

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Rockwell Hardness Tester' category

Brinell Hardness Testing Machine Minimum Order Quantity : 1 Operate Method : Automatic Power Supply : Electric Product Type : Brinell Hardness Testing Machine Usage : Industrial
