Digital Thickness Gauge

Name: Digital Thickness Gauge
Brand: HEAT TREATMENT SALES & SERVICES
Price: 19500 INR
Availability: InStock

19500 INR/Set

Get a Price/Quote

Product Details:

Display Digital
Frequency 50 Hertz (HZ)
Usage Industrial
Product Type Digital Thickness Gauge
Color Black
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Digital Thickness Gauge Price And Quantity

Price 19500 INR/Set
Minimum Order Quantity 1 Set

Digital Thickness Gauge Product Specifications

Product Type Digital Thickness Gauge
Frequency 50 Hertz (HZ)
Display Digital
Usage Industrial
Color Black

Digital Thickness Gauge Trade Information

Supply Ability 1 Set Per Month
Delivery Time 2-3 Days

Product Description

Product Details:

Model Name/Number	TT 100
Brand	TIME
Measuring Range	0.70 to 225.0 mm
Display	LCD
Type	Digital
Accuracy	+/-1% of Material Thickness
Weight	170g
Least Count	0.1mm
Size	126 x 68 x 23 mm
Battery Life	250 hours per battery set
Battery Type	2 x 1.5 AA Alkaline
Operating Temperature	< 60 deg C
Warranty	12 Month

TIME TT 100 is a hand held microprocessor controlled thickness gauge specifically designed for measuring the thickness of metallic and non-metallic materials e.g. aluminium, titanium, plastics, ceramics, glass and other good ultrasonic wave-conducting as long as the material has parallel top and bottom surfaces.
With uses in many areas of industry TT100 can perform precise measurements on various types of raw materials, components parts, and assembled machinery. It can also be used to monitor all types of pipes and pressure vessels for loss of thickness due to corrosion.
TT100 is very easy to use, after a simple calibration to a known thickness or sound velocity, the gauge will give fast and accurate readings in millimetres. Sound velocities for 5 different materials can be pre-set and 10 thickness readings can be stored in the memory

Specifications
Material : Metallic & Non-Metallic
Measuring units : mm
Range (probe dependant) : 1.0 to 225.0 mm
Frequency : 5 MHz
Accuracy :+/-1% of Material Thickness + 0.1 mm
Display : 4 digit LCD
Resolution : 0.1 up to 99.9 mm
Memory : 10 readings
Sound velocity range : 1000 to 9999 m/sec
RS232 :no
Probe Tip diameter : 12 mm
Sound Velocity : 5 Preset Sound Velocities
Pipe Diameter Limits : 20 mm x 3 mm
Auto power off : Yes
Working Temp. : -5 to 40 deg C
Power Supply :2 x 1.5 AA Alkaline
Relative Humidity :< 90%
Alarm limit setting : No
Surface Temperature : < 60 deg C
Battery Life : 250 hours per battery set
Dimensions :126 x 68 x 23 mm

Weight :170g

We have marked a distinct position in the market by providing Digital Thickness Gauge . This gauge is designed and engineered using supreme class raw material in compliance with set industry standards. We assure our valuable clients that provided gauge is precisely checked on several quality parameters. Furthermore, the offered gauge is used in various engineering industries to measure the thickness of the metal sheets. This Digital Thickness Gauge is offered in varied specifications at very reasonable price to the clients.
