TT 100 Digital Ultrasonic Thickness Gauge

TT 100 Digital Ultrasonic Thickness Gauge

5000-200000 INR/Set

Product Details:

X

Price And Quantity

  • 1 Set
  • 5000-200000 INR/Set

Trade Information

  • 1 Set Per Month
  • 2-3 Days

Product Description

Product Details :

Model Name/Number

TT 100

Brand

TIME

Measuring Range

0.70 to 225.0 mm

Display

LCD

Type

Digital

Accuracy

+/-1% of Material Thickness

Weight

170g

Least Count

0.1mm

Size

126 x 68 x 23 mm

Battery Life

250 hours per battery set

Battery Type

2 x 1.5 AA Alkaline

Operating Temperature

< 60 deg C

Warranty

12 Month

Specifications :

  • Material : Metallic & Non-Metallic
  • Measuring units : mm
  • Range (probe dependent) : 1.0 to 225.0 mm
  • Frequency : 5 MHz
  • Accuracy :+/-1% of Material Thickness + 0.1 mm
  • Display : 4 digit LCD
  • Resolution : 0.1 up to 99.9 mm
  • Memory : 10 readings
  • Sound velocity range : 1000 to 9999 m/sec
  • RS232 :no
  • Probe Tip diameter : 12 mm
  • Sound Velocity : 5 Preset Sound Velocities
  • Pipe Diameter Limits : 20 mm x 3 mm
  • Auto power off : Yes
  • Working Temp. : -5 to 40 deg C
  • Power Supply :2 x 1.5 AA Alkaline
  • Relative Humidity :< 90%
  • Alarm limit setting : No
  • Surface Temperature : < 60 deg C
  • Battery Life : 250 hours per battery set
  • Dimensions :126 x 68 x 23 mm
  • Weight :170g
