Industrial Video Borescope

Product Description

Features:

• High-End Video Borescope with Added Functionality.
• Joystick-Controlled, 360 Articulation.
• Highly Durable and Flexible Insertion Tube.
• Super High-Intensity LED Illumination.
• True Portability in a Compact Package.
• Battery Powered Operation.

Applications:

• Machinery, Casting, Chemical Industry, Water Treatment, Auto, Army, Police, Fire Control, and so on.

Technical parameters :

• Camera outer diameter: 4mm/6mm
• Effective working length: 1.5-3m
• FOV : 90^o /120^o
• DOF : 15mm-
• Pixels : 300,000
• Camera protective function: IP64, up to Ip67
• Testing cable material: Stainless Steel braid
• Guider bend angle : refer to attached table
• Guider bend directions : 4-way
• Guider bend radius : refer to attached table
• Illumination and power control LED cold light source
• Light intensity : 40000Lux~60000Lux
• brightness adjust mode : Yes
• Power : 12.6V ~1A
• Portable battery: Dismountable
• continuous working time : 4h~5h
• Monitor size : 3.5" TFT LCD
• Definition (Resolution ) : 800*600
• video format : AVI format
• picture format : JPEG format
• Storage capacity 8G SD card
• Host system working temperature -10^oC~50^oC
