VT Series Industrial Videoscope

We have established a reputation for ourselves in the market as a trustworthy supplier of VT Series Industrial Videoscope. This is precisely manufactured using the finest grade materials under the guidance of our experts. It is designed for different load ranges and offer various degrees of operator convenience. Moreover, this VT Series Industrial Videoscope  is available in different specifications at discount prices.

Product Specifications :

Video Probe Technical Parameter :

• Available Probe Diameters: 4mm, 6mm, 8mm
• Effective working length: 1m-3m
• Field of View: 70^o, 90^o, 120^o
• Depth of field: 15mm- 25mm-
• CCD/CMOS specification: 1/10", 1/8", 1/4"
• Available pixel: 300,000 Pixels, 440,000 Pixels
• White balance: factory default
• Waterproof: IP64 can up to IP67
• Material of testing line: Soft line (or 20m coil hard wire)

Illumination Type and power supply control :

• Illumination Type: White LED
• Light intensity: 65000Lux
• Color Temperature: 5600k
• Lamp life: above 10000 hours
• Power supply: DC12V 1A
• Portable battery: Li-polymer 5V 4500 mAH

Image Display technical specifications :

• Specification of Monitor: 4.3" TFT LCD
• Resolution: 800 X 480
• Image signal Output: CVBS Composite video

Image storage and processing specifications :

• Video storage format: DI: 25f/s VGA: 30f/s
• Image storage format: JPEG
• Storage capacity: 8G(up to 32G)

Host performance and working environment :

• Host control mode: Handset integrated operation
• System Weight: 0.95kg
• System Operating Tempe ration: -10 to 50
• Relative humidity: 30%-80%RH
